Tungsten Carbide Components

Professional Tungsten Carbide Components Manufacturer

We specialize in the manufacturing of precision tungsten carbide components used in high-wear and high-precision industrial applications. Our carbide components offer excellent hardness, wear resistance, corrosion resistance, and long service life under demanding working conditions. We offer low-cost custom manufacturing services with MOQ starting from 1 piece.

Our Tungsten Carbide Components Products

Custom Tungsten Carbide Components Machining Capabilities

As an experienced tungsten carbide machining manufacturer, we provide precision carbide components for industrial machinery, tooling systems, and wear-resistant equipment.

  • Minimum machinable straight hole diameter: 0.06mm with material thickness of 0.6mm
  • Internal hole surface finish by EDM: up to Ra 0.2
  • External surface polishing roughness range: from Ra 0.02 to Ra 1.6
  • Sharp corner machining capability: minimum inner corner radius up to R0.015mm
  • Tolerance ±0.001 mm, concentricity ±0.002 mm
  • Precision grinding for complex carbide components
  • Strict dimensional tolerance and surface finish control
  • Custom carbide wear parts, tooling components, and precision mechanical parts

How to Choose the Tungsten Carbide Grade for Components Products

Tungsten carbide components generally refer to various mechanical parts or mold components, excluding cutting tools. These parts are widely used in applications involving wear, sealing, guiding, or structural support, often operating under complex conditions such as friction, load, corrosion, or temperature variation.

When selecting the appropriate carbide grade, key factors include the specific function of the component, contact conditions (sliding, sealing, or static), load level, and the operating environment. Grades with higher hardness provide superior wear resistance for components exposed to abrasion, while grades with higher binder content (such as cobalt or nickel) offer improved toughness and resistance to impact or mechanical stress.

For components used in corrosive or chemically aggressive environments, corrosion-resistant carbide grades should be considered. In applications requiring tight tolerances and dimensional stability, fine-grain carbide grades are often preferred. Typically, the ISO K series tungsten carbide grades are used.

Corresponding Chinese tungsten carbide grades. For example, K10 corresponds approximately to YG6 (high wear resistance), K20 to YG8 (general purpose), and K30–K40 to YG10–YG15 (higher toughness grades). Final grade selection depends on wear conditions, impact load, and service life requirements.

K10, K15, K20, K30, K40 Grade Equivalency Table (YG6, YG8, YG10, YG15)

ISO Grade General Characteristics Common Chinese Grade Reference
K10 High hardness, low cobalt content, excellent wear resistance YG6 / YG6X
K15 Slightly improved toughness while maintaining good wear resistance YG6X / YG8X
K20 General-purpose grade with balanced wear resistance and toughness YG8
K30 Better toughness and impact resistance YG10 / YG10X
K40 High toughness and high cobalt content, suitable for higher impact conditions YG13 / YG15
ISO Grade Comparison for Tungsten Carbide Across Different Brands
China Carbide Grades Guide: K10, K20, K30, K01 & More

Available Tungsten Carbide Grades

We offer a wide range of tungsten carbide grades to meet various application requirements, including materials with different cobalt (Co) contents and customized compositions. Our carbide machining services support processing of tungsten carbide materials containing nickel (Ni), molybdenum (Mo), chromium (Cr), titanium (Ti), tantalum (Ta), niobium (Nb), vanadium (V), and other alloying elements in different proportions.

According to specific working conditions and performance requirements, we can provide machining services for carbide materials from different grades and brands, designed for high hardness, high wear resistance, corrosion resistance, and high impact resistance. We can recommend materials based on the technical specifications of the products provided.

Applications of Tungsten Carbide Components

Tungsten carbide components are widely used in industries requiring high wear resistance, high hardness, and long service life.

  • Oil and gas drilling equipment
  • Mining and mineral processing machinery
  • Automotive manufacturing
  • Aerospace components
  • Electronics and semiconductor industry
  • Metal forming and stamping tools
  • Precision industrial machinery

Frequently Asked Questions

Q: Can you manufacture carbide components according to drawings?
A: Yes. We specialize in custom tungsten carbide components according to customer drawings, samples, and technical requirements.

Q: What is the minimum order quantity?
A: The minimum order quantity is 1 piece. We support prototype and small batch production.

Q: What is the typical tolerance for custom tungsten carbide components?
A: Tolerance requirements vary depending on the application and functional priorities of the part. Typical tolerances range from +/-0.1 mm to +/-0.001 mm. For example, some tungsten carbide balls are required to have a tolerance of only +/-0.1 mm, die components require a tolerance of +/-0.002 mm, and mechanical components require a tolerance of +/-0.005 mm.

Q: What materials can you machine?
A: We can process tungsten carbide, mold steel, HSS, tool steel, copper, as well as other metals and ceramic materials.

Q: How are the products packaged and shipped?
A: Products are carefully packed in paper boxes or wooden cases depending on size and weight. Shipments are usually delivered by international express services.

Q: What is the production lead time?
A: The typical production time is 12–30 days depending on product quantity and complexity.

Get a Quote for Custom Tungsten Carbide Components

Send your drawings or requirements. MOQ 1 piece. Fast response within 24 hours.
